Jie Jin Dangerous Goods Small Classroom-1
The first category: explosive substances and articles
Classes 1.1, 1.2 and 1.3
Symbol (explosive bomb): black; background color: orange yellow; number "1" written in the bottom corner
(NO.1.4)
Class 1.4
(NO.1.5)
Class 1.5
(NO.1.6)
Class 1.6
Background color: orange yellow; number: black; number height is about 30mm, font stroke width is about 5mm (for 100mmX100mm logo); number "1" is written at bottom corner
** Locations belonging to the hazard category - leave blank if it is sub-hazard
* The location of the fitting group - if it is a sub-hazard, leave it blank
The second category: gas
(NO.2.1 )
Class 2.1 flammable gas
Symbol (flame): black or white; background color: red; number "2" written in the bottom corner
(NO.2.2)
Class 2.2 Non-flammable, non-toxic gases
Symbol (cylinder): black or white; background color: green; number "2" written in the bottom corner
(NO.2.3)
Symbols (skull and cross bones stick): black; background: white; the number "2" in the bottom corner
The third category: flammable liquid
NO.3)
Symbol (flame): black or white; background color: red; number "3" written in the bottom corner
(NO.4.1)
Class 4.1 Flammable solid
Symbol (flame): black;Background color: white plus seven vertical red strips;The number "4" is written in the bottom corner
(NO.4.2)
Class 4.2 Easy pyrophoric materials
Quality symbol (flame): black;Background color: the three halves are white and the lower half is red;The number "4" is written in the bottom corner
(NO.4.3 )
Class 4.3 Water flammable
Symbol (flame): black or white;Background color: blue;The number "4" is written in the bottom corner
Fifth category
(NO.5.1)
Class 5.1 oxidant (substance)
Symbol (with flame on the circle): black; background: yellow;The number "5.1" is written in the bottom corner
(NO.5.2)
Class 5.2 Organic peroxides
Symbol (with flame on the circle): black; background: yellow;The number "5.2" is written in the bottom corner
Fifth category
(NO.6.1)
Class 6.1 Toxic substances
Symbols (skull and cross bones stick): Black;Background color: white; number "6" written in the bottom corner
(NO.6.2)
Class 6.2 Infectious substances
The lower part of the logo can be marked with "INFECTIOUS SUBSTANCE" (infectious substances) and"In the case of damage of leakage immediatey notify Public Health Authority" ("In the event of damage or leakage, notify the public health agency immediately)Symbols (three new moon symbols overlap together along a circle) and text: black; background color: white; number "6" written in the bottom corner
Category 7: Radioactive materials
(NO.7A)
Level I - white
Symbol (three-leaf type): black; background color: white;Text: (mandatory), marked in bold in the lower part of the logo: RADIOACTIVE (radioactive) CONTENTS... (content name) ACTIVITY... (intensity is...)Immediately followed by the word "radioactive" marked with a vertical red short bar; the number "7" is written at the bottom corner
(NO.7B)
Level II----Yellow
Symbol (three-leaf type): black; background color: upper half yellow with white edges and lower half white.Text: (mandatory), marked in bold in the lower part of the logo: RADIOACTIVE (radioactive) CONTENTS... (content name) ACTIVITY... (intensity is...)Marked in a black box: TRANSPORT INDEX.. (Transportation Index)Two red vertical bars are marked on the back of the word "radioactive"The number "7" is written in the bottom corner
(NO.7C)
Level III----Yellow
Symbol (three-leaf type): black; background color: upper half yellow with white edges and lower half white.Text: (mandatory), marked in bold in the lower part of the logo: RADIOACTIVE (radioactive) CONTENTS... (content name) ACTIVITY... (intensity is...)
Marked in a black box: TRANSPORT INDEX.. (Transportation Index)
Follow the words "radioactive" on the back with three vertical red barsThe number "7" is written in the bottom corner
(NO.7E)
Class 7 fissile material
Background color: white; text (mandatory), marked in bold in the upper part of the logo: FISSILE (fission):Marked in a black box: Criticality Safety index... The number "7" iswritten in the bottom corner
Category 8: Corrosives
(NO.8)
Symbol (liquid, escaping from two glass containers to the hands and metal): black;Background color: the upper half is white, the lower half is black with white edges; the number "8" is written at the bottom corner
Category 9: Miscellaneous dangerous substances and articles
(NO.9)
Symbol (7 vertical strips in the upper half): black; background color: white; number "9" written in the bottom corner
